DIN Metric Plug and Caps

DIN METRIC PLUG SEAL TYPES:
DIN Metric ISO 6149-4 PLEH PLIH Hex Port Plug
Metric ISO 9974-4 PLEH PLIHS Hex Port Plug
DIN 908 Internal Drive Screw Plug with Metric Thread
DIN 910 Hex Head Screw Plugs with Metric Thread
ISO 8434-4 Female Metric Swivel Caps DKO

Shapes of DIN Plug and Caps
Internal Hex Plug
External Hex Plug
Hex Head Plug
Internal Drive Screw Plug
Female DKO Swivel Caps

Match Port types Standards As Follows:
ISO 6149-1 / SAE J2244 O-ring Seal Metric Port
ISO 9974-1 / DIN 3852-1 Metric Flat Face Seal Port

Tube End Connection Types:
24 degree cone connector
Port End Connection Types:
Metric O-ring port
Shapes of Hydraulic Fittings:
Plug and Cap

Availability:



Inquire PDF Export

Metric Hydraulic Caps and Plugs | DIN 908 Screw Plug

DIN Metric Plug and Caps Introduction

All DIN ISO Metric Plugs is design with Metric thread ISO 261 for hydraulic fluid power applications, but there are many types of assembling purposes such as Internal hex plug with ISO 6149-4 and ISO 9974-4; Internal drive screw plug with DIN 908; External hex plug with ISO 6149-4, ISO 9974-4; External hex head plug with DIN 910. Two Types of metric stud seal such as ISO 6149-1 / SAE J2244 O-ring Seal Metric Port and ISO 9974-1 / DIN 3852-1 Metric Flat Face Seal Port. Another is designed with 24 degree cone o-ring(DKO) blanking plug, it is assembled with ISO 261 metric female thread nut(also called Caps), it is used for plugging male connector with 24 degree cone tube end.

Overview catalogue Of DIN Metric Plug and Caps

DIN Metric plug and caps is made of these shapes(Parker-Eaton series no), from forging/shape material as follows:

ROV/4C 4D DIN 2353/ISO8434-1

VSTI M-OR/4MN-OR ISO 6149-4

VSTI M-ED/4MN-ED ISO 9974-4

VKAM/9C 9D DIN 2353/ISO 8434-4

ISO 10664 / DIN 34824 Screw Drive DIN 908 Plug

Screw Drive DIN 908 Plug

DIN 910 Hex Head Screw Plug

Dimensions Of ISO 6149-4 internal hex port plugs

Figure of Internal hex port plug(PLIH)

Stud end details in accordance with ISO 6149-2

Screw Threads	d10	d11	d12	d14	L4	L13	L14	L15	L16	L17	s
M8x1	11.8	4.6	4	4.7	9.5	3	5	3.5	13	2.1	4
M10x1	13.8	5.8	5	5.9	9.5	3	5.5	4	13.5	2.1	5
M12x1.5	16.8	6.9	6	7	11	3	7.5	4.5	15.5	2.5	6
M14x1.5	18.8	6.9	6	7	11	3	7.5	5	16	2.5	6
M16x1.5	21.8	9.2	8	9.3	12.5	3	8.5	5	17.5	2.5	8
M18x1.5	23.8	9.2	8	9.3	14	3	8.5	5	19	2.5	8
M20x1.5a	26.8	11.5	10	11.6	14	3	8.5	5	19	2.9	10
M22x1.5	26.8	11.5	10	11.6	15	3	8.5	5	20	2.9	10
M27x2	31.8	13.9	12	14	18.5	3	10.5	5	23.5	3.7	12
M30x2	35.8	16.2	14	16.3	18.5	3	11	6	24.5	3.7	14
M33x2	40.8	16.2	14	16.3	18.5	3	11	6	24.5	3.7	14
M42x2	49.8	19.6	17	19.7	19	3	11	6	25	3.7	17
M48x2	54.8	19.6	17	19.7	21.5	3	11	6	27.5	3.7	17
M60x2	64.8	21.9	19	22	24	3	12	6	30	3.7	19

M20x1.5 a only for cartridge valve cavity application ISO 7789.

b is Identification groove 1 mm wide x 0.25 mm deep, as an optional shape.

Dimensions Of ISO 9974-4 internal hex port plugs

Dimensions Of ISO 9974-4 internal hex port plugs

Figure of Internal hex port plug(PLIHS)

Stud end details in accordance with ISO 9974-2

Screw Thread	d2	d3	d4	L4	L12	L13	L14	L15	L16	s
M10×1	14	5	5.9	8	12.3	4.3	5	2	3	5
M12×1.5	17	6	7	12	17.3	5.3	7	2	3	6
M14×1.5	19	6	7	12	17.3	5.3	7	2	3	6
M16×1.5	22	8	9.3	12	17.3	5.3	7	2	3	8
M18×1.5	24	8	9.3	12	17.3	5.3	7	2	3	8
M20×1.5a	26	10	11.6	14	19.3	5.3	7.5	2	3	10
M22×1.5	27	10	11.6	14	19.3	5.3	7.5	2	3	10
M26×1.5	32	12	14	16	21.3	5.3	9	2.4	3	12
M27×2	32	12	14	16	21.3	5.3	9	2.4	3	12
M33×2	40	17	19.7	16	22.8	6.8	9	2.5	3	17
M42×2	5o	22	25.5	16	22.8	6.8	10.5	2.5	3	22
M48×2	55	24	27.8	16	22.8	6.8	10.5	2.5	3	24

M20×1.5a is for measurement applications.

b is optional socket undercut d4xL15.

Dimensions Of DIN 908 internal drive screw plugs

Internal Hex type of form A as per DIN 3852-1 and DIN 3852-2

Internal Hex type of form A as per DIN 3852-1 and DIN 3852-2

EN DIN ISO 10664 Hexalobular internal driving type of form A as per DIN 3852-1 and DIN 3852-2

EN DIN ISO 10664 Hexalobular internal driving type of form A as per DIN 3852-1 and DIN 3852-2

DIN 3482 12 point socket driving type of form A as per DIN 3852-1 and DIN 3852-2

DIN 3482 12 point socket driving type of form A as per DIN 3852-1 and DIN 3852-2

Dimensions of DIN 908 screw drive plug

Dimensions of DIN 908 screw plug

Dimensions Of DIN 910 Hexagon head screw plugs with metric thread

Dimensions Of DIN 910 Hexagon head screw plugs with metric thread

1 is male stud in accordance with form A of DIN 3852-1 and DIN 3852-2

2 is permanent magnet.

Dimensions Of DIN 910 Hexagon head screw plugs with metric thread chart

4C 4D DIN Metric blanking plug for tube ends

DIN 24°cone end, Parker ROV series

4C 4D DIN Metric blanking plug for tube ends

PART NO.	PARKER NO.	E	D1	l1	L1	S1	S2
L SERIES
4C-12	ROV06L	M12x1.5	6	7	22	12	14
4C-14	ROV08L	M14x1.5	8	8	23	14	17
4C-16	ROV10L	M16x1.5	10	9	24	17	19
4C-18	ROV12L	M18x1.5	12	10	25	19	22
4C-22	ROV15L	M22x1.5	15	11	26	24	27
4C-26	ROV18L	M26X1.5	18	11.5	28	27	32
4C-30	ROV22L	M30x2	22	13.5	30	32	36
4C-36	ROV28L	M36x2	28	14.5	31	41	41
4C-45	ROV35L	M45X2	35	14.5	36	46	50
4C-52	ROV42L	M52X2	42	16	39	55	60
S SERIES
4D-14	ROV06S	M14X1.5	6	11	26	14	17
4D-16	ROV08S	M16X1.5	8	13	28	17	19
4D-18	ROV10S	M18x1.5	10	12.5	29	19	22
4D-20	ROV12S	M20x1.5	12	14.5	31	22	24
4D-22	ROV14S	M22x1.5	14	16	34	24	27
4D-24	ROV16S	M24x1.5	16	15.5	34	27	30
4D-30	ROV20S	M30x2	20	17.5	39	32	36
4D-36	ROV25S	M36x2	25	20	44	41	46
4D-42	ROV30S	M42x2	30	20.5	47	46	50
4D-52	ROV38S	M52X2	38	23	54	55	60f

4MN-WD Metric internal hex plug for port

Male Metric Thread with ISO 9974 ED seal, Parker VSTI M-ED series

4MN-WD Metric internal hex plug for port

PART NO.	PARKER NO.	E	CAPTIVE SEAL	A	L	S1
4MN-10WD	VSTI10X1ED	M10X1	WD-B02	8	12	5
4MN-12WD	VSTI12X1.5ED	M12X1.5	WD-M12	12	17	6
4MN-14WD	VSTI14X1.5ED	M14X1.5	WD-B04	12	17	6
4MN-16WD	VSTI16X1.5ED	M16X1.5	WD-M16	12	17	8
4MN-18WD	VSTI18X1.5ED	M18X1.5	WD-M18	12	17	8
4MN-20WD	VSTI20X1.5ED	M20X1.5	WD-M20	14	19	10
4MN-22WD	VSTI22X1.5ED	M22X1.5	WD-M22	14	19	10
4MN-26WD	VSTI26X1.5ED	M26X1.5	WD-B12	16	21	12
4MN-27WD	VSTI27X2ED	M27X2	WD-B12	16	21	12
4MN-33WD	VSTI33X2ED	M33X2	WD-B16	18	24.5	17
4MN-42WD	VSTI42X2ED	M42X2	WD-B20	20	26.5	22
4MN-48WD	VSTI48X2ED	M48X2	WD-B24	22	28.5	24

4MN-OR Metric internal hex plug for port

Male Metric Thread with ISO 6149 o-ring seal, Parker VSTI M-OR series

4MN-OR Metric internal hex plug for port ISO 6149 SCREW PLUG

Stud end details in accordance with ISO 6149-2

PART NO.	PARKER NO.	Threads	d10	d11	d12	d14	L4	L13	L14	L15	L16	L17	s
4MN-10OR	VSTI10X1OR	M10x1	13.8	5.8	5	5.9	9.5	3	5.5	4	13.5	2.1	5
4MN-12OR	VSTI12X1.5OR	M12x1.5	16.8	6.9	6	7	11	3	7.5	4.5	15.5	2.5	6
4MN-14OR	VSTI14X1.5OR	M14x1.5	18.8	6.9	6	7	11	3	7.5	5	16	2.5	6
4MN-16OR	VSTI16X1.5OR	M16x1.5	21.8	9.2	8	9.3	12.5	3	8.5	5	17.5	2.5	8
4MN-18OR	VSTI18X1.5OR	M18x1.5	23.8	9.2	8	9.3	14	3	8.5	5	19	2.5	8
4MN-20OR	VSTI20X1.5OR	M22x1.5	26.8	11.5	10	11.6	15	3	8.5	5	20	2.9	10
4MN-22OR	VSTI22X1.5OR	M27x2	31.8	13.9	12	14	18.5	3	10.5	5	23.5	3.7	12
4MN-27OR	VSTI27X2OR	M30x2	35.8	16.2	14	16.3	18.5	3	11	6	24.5	3.7	14
4MN-33OR	VSTI33X2OR	M33x2	40.8	16.2	14	16.3	18.5	3	11	6	24.5	3.7	14
4MN-42OR	VSTI42X2OR	M42x2	49.8	19.6	17	19.7	19	3	11	6	25	3.7	17
4MN-48OR	VSTI48X2OR	M48x2	54.8	19.6	17	19.7	21.5	3	11	6	27.5	3.7	17

Identification groove 1 mm wide x 0.25 mm deep, as an optional shape.

4M-BW DIN Metric Bonded Washer Plug

For DIN 3852-1/ ISO 9974-1 Port

4M-BW DIN Metric Bonded Washer Plug

PART NO.	THREAD d	H	L	N
4M-08BW	M8x1	7.5	8	12
4M-10BW	M10x1	7.5	8	14
4M-12BW	M12x1.5	7.5	12	17
4M-14BW	M14x1.5	7.5	12	19
4M-16BW	M16x1.5	7.5	12	22
4M-18BW	M18x1.5	8	12	24
4M-20BW	M20x1.5	8	14	27
4M-22BW	M22x1.5	8	14	27
4M-24BW	M24x1.5	10.5	14	30
4M-26BW	M26x1.5	10.5	16	32
4M-28BW	M28x1.5	10.5	16	36
4M-30BW	M30x1.5	10.5	16	36
4M-32BW	M32x1.5	10.5	16	41

If need Bonded washer assembly, please indicate as the Part NO. 4M-08OR. If no, please indicated 4M-14ORN.

4M-BW DIN Metric Bonded Washer Plug assembly

4M-OR Metric O-ring Port Plug

For ISO 6149-1/ SAE J2244 Port

4M-OR Metric O-ring Port Plug

PART NO	THREAD	L4	L5	L11	S
4M-08OR	M8x1	9,5	1,6	16,5	12
4M-10OR	M10x1	9,5	1,6	17	14
4M-12OR	M12x1,5	11	2,5	18,5	17
4M-14OR	M14x1,5	11	2,5	19,5	19
4M-16OR	M16x1,5	12,5	2,5	22	22
4M-18OR	M18x1,5	14	2,5	24	24
4M-20OR	M20x1,5	14	2,5	25	27
4M-22OR	M22x1,5	15	2,5	26	27
4M-24OR	M27 × 2	18,5	2,5	31,5	32
4M-26OR	M30 × 2	18,5	2,5	33	36
4M-28OR	M33 × 2	18,5	3	34	41
4M-30OR	M42 × 2	19	3	36,5	50
4M-32OR	M48 × 2	21,5	3	40	55

Identification groove 1 mm wide x 0.25 mm deep, as an optional shape.

4M-OR Metric O-ring Port Plug assembly

Note: 4M-08OR is with O-ring delivery, if no need, please indicate 4M-08ORN

9C 9D Metric Swivel Plug

ISO 8434-4 Female Swivel 24 degree cone plug with O-ring DKO, Parker VKAM series

9C 9D Metric Swivel Plug

PART NO.	PARKER NO.	F	D	O-RING	L	L1	S2
L SERIES
9C-12	VKAM06L	M12X1.5	6	O04.5x1.5	15.5	17.5	14
9C-14	VKAM08L	M14X1.5	8	O06.5x1.5	15.5	18	17
9C-16	VKAM10L	M16X1.5	10	O08.0x1.5	16.5	18	19
9C-18	VKAM12L	M18X1.5	12	O10.0x1.5	18	19.5	22
9C-22	VKAM15L	M22X1.5	15	O12.0x2.0	18.5	20	27
9C-26	VKAM18L	M26X1.5	18	O15.0x2.0	19.5	22	32
9C-30	VKAM22L	M30X2	22	O20.0x2.0	21.5	22.5	36
9C-36	VKAM28L	M36X2	28	O26.0x2.0	22.5	24.5	41
9C-45	VKAM35L	M45X2	35	O32.0x2.5	25	29	50
9C-52	VKAM42L	M52X2	42	O38.0x2.5	27	31.5	60
S SERIES
9D-14	VKAM06S	M14X1.5	6	O04.5x1.5	16	18	17
9D-16	VKAM08S	M16X1.5	8	O06.5x1.5	16.5	18.5	19
9D-18	VKAM10S	M18X1.5	10	O08.0x1.5	18	20	22
9D-20	VKAM12S	M20X1.5	12	O10.0x1.5	18.5	20.5	24
9D-22	VKAM14S	M22X1.5	14	O11.0x2.0	19	21.5	27
9D-24	VKAM16S	M24X1.5	16	O13.0x2.0	18.5	21.5	30
9D-30	VKAM20S	M30X2	20	O16.3x2.4	22.5	25	36
9D-36	VKAM25S	M36X2	25	O20.3x2.4	23.5	28.5	46
9D-42	VKAM30S	M42X2	30	O25.3x2.4	25.5	32	50
9D-52	VKAM38S	M52X2	38	O33.3x2.4	26.5	36	60
