BSPP flat face port, Metric flat face port
Straight
Availability: | |
---|---|
PDF Export | |
Connects under full pressure
With protective metal cap
Stud end with various thread sealing
20 carbon steel, 316 stainless steel
M162-SERIES Diagnostic coupling hydraulic test adapter
M16x2 test coupling to Flat face stud ends/ports as chart:
To Metric male stud: ED sealing DIN EN ISO 9974-2(Type E) for DIN EN ISO 9974-1 port.
To BSPP male stud: ED sealing ISO 1179-2(Type E) for ISO 1179-1 port.
Part No. | G thread Size | L | J | CH |
M162-M10-E | M10x1 | 37 | 8 | 17 |
M162-M12x1.25-E | M12x1.25 | 37 | 10 | 17 |
M162-M14x1.5-E | M14x1.5 | 37 | 12 | 19 |
M162-M16x1.5-E | M16x1.5 | 37 | 12 | 22 |
M162-G1/8-E | G1/8” | 37 | 8 | 17 |
M162-G1/4-E | G1/4” | 37 | 12 | 19 |
M162-G3/8-E | G3/8” | 37 | 14 | 22 |
M162-G1/2-E | G1/2” | 37 | 16 | 27 |
Seal Type |
Thread | J mm |
CH mm | Working Pressure (bar) |
Part Number |
E | M8x1 | 8 | 17 | 400 | SD-M16x2-E-M8x1 |
M10x1 | 8 | 17 | 400 | SD-M16x2-E-M10x1 | |
M10x1.25 | 8 | 17 | 400 | SD-M16x2-E-M10x1.25 | |
M12x1.5 | 12 | 17 | 630 | SD-M16x2-E-M12x1.5 | |
M14x1.5 | 12 | 19 | 630 | SD-M16x2-E-M14x1.5 | |
M16x1.5 | 12 | 22 | 630 | SD-M16x2-E-M16x1.5 | |
M18x1.5 | 12 | 24 | 400 | SD-M16x2-E-M18x1.5 | |
M20x1.5 | 14 | 27 | 400 | SD-M16x2-E-M20x1.5 | |
M22x1.5 | 14 | 27 | 400 | SD-M16x2-E-M22x1.5 | |
M26x1.5 | 16 | 32 | 400 | SD-M16x2-E-M26x1.5 | |
M27x2 | 16 | 32 | 400 | SD-M16x2-E-M27x2 | |
M33x2 | 18 | 41 | 400 | SD-M16x2-E-M33x2 | |
M42x2 | 20 | 50 | 315 | SD-M16x2-E-M42x2 | |
M48x2 | 22 | 55 | 315 | SD-M16x2-E-M48x2 | |
F | G1/8” | 8 | 17 | 400 | SD-M16x2-F-G1/8” |
G1/4” | 12 | 19 | 630 | SD-M16x2-F-G1/4” | |
G3/8” | 12 | 22 | 630 | SD-M16x2-F-G3/8” | |
G1/2” | 14 | 27 | 630 | SD-M16x2-F-G1/2” | |
G3/4” | 16 | 32 | 630 | SD-M16x2-F-G3/4” | |
G1” | 18 | 41 | 400 | SD-M16x2-F-G1” | |
G1 1/4” | 20 | 50 | 315 | SD-M16x2-F-G1 1/4” | |
G1 1/2” | 22 | 55 | 315 | SD-M16x2-F-G1 1/2” |
