A crisp, white-background studio shot of a steel DIN 908 internal hexagon socket screw plug highlighting its precision-machined sharp metal sealing edge.

A real-world application photo showing multiple DIN 908 M10x1 metric screw plugs blocking unused outlet ports flush on an automated grease distributor block.

DIN 908 Hexagon Socket Screw Plug with Metal Sealing Edge for Lubrication Grease Blocks

Tube End Connection Types:
24 degree cone connector
Port End Connection Types:
Metric O-ring port
Shapes of Hydraulic Fittings:
Straight
Hose End Connection Type:
One wire braid hoses

Availability:



Inquire PDF Export

Product Description

DIN 908 Hexagon Socket Screw Plug with Metal Sealing Edge for Lubrication Grease Blocks

Product Overview

Seal off unused manifold or progressive distribution ports with complete confidence using our premium DIN 908 Hexagon Socket Screw Plug. Specifically engineered for high-pressure grease blocks and centralized lubrication manifolds, this parallel-threaded blanking plug features a precision-machined Type A metal sealing edge (cutting face). When torqued into place, the sharp concentric sealing ridge bites directly against the housing face, creating a permanent, highly dependable metal-to-metal barrier. It completely eliminates the need for soft washers or elastomeric seals that degrade over time.

A clear technical drawing outlining the metric thread sizes, hex socket depths, and overall pitch parameters for a DIN 908 internal drive threaded plug

Part No.	Description	G	D	L1	L2	SW1
4MN-10B	Screw Plug M10x1 -B	M10x1	14	9,5	4,5	5

Key Features & Benefits

Strict DIN 908 Compliance: Precision-manufactured to global engineering metrics for an exact, flush-mount fit.
Leak-Free Metal Sealing Edge: The integrated concentric cutting ridge forms a tight, permanent mechanical seal resilient against harsh chemicals and thermal spikes.
Low-Profile Hex Socket Drive: Internal hexagon socket design allows for streamlined, flush installation inside crowded machine compartments and valve banks.
Extreme Pressure Endurance: Rated to withstand continuous cycling pressures up to 400 Bar (5,800 PSI) common in heavy-duty automated progressive grease blocks.

Technical Specifications

Standard Specification: DIN 908 / ISO 1179-4
Drive Type: Internal Hexagon Socket (Allen Key Drive)
Sealing Interface: Type A Metal Sealing Edge (Concentric Cutting Face)
Common Thread Options: M8x1, M10x1, M14x1.5, G1/8", G1/4" Parallel Threads
Material Integrity: High-tensile forged carbon steel or premium stainless steel (SS316) options.
Surface Protection: Heavy-duty trivalent zinc or zinc-nickel plating for outstanding corrosion defense.

Applications

Universally integrated into centralized lubrication progressive blocks, hydraulic manifold blocks, automated grease distribution valves, process pumps, and automotive engine gearboxes.
